Product - Technical Specs
Power supply:
AC120V, 60Hz; Current:3.5A; Power: 450VA
Sound level:
≤ 50dB (A) Acoustic power level: 58.5dB (A)
Maximum recommended flow:
5L/min
Flow Range at Outlet Pressure of 0 kPa:
0.5~5L/min
Oxygen Concentration:
When 0.5~5L/min ,93%±3% (after turning on 30 minutes)
Output Pressure:
38kPa±5kPa
Release Pressure during machine operation:
250kPa±50kPa
Weight:
35.5lbs
Dimension:
13”×10.3”×21.3” (330×260×540mm
Altitude:
The oxygen concentration will not reduce at altitudes up to 6,000ft / 1828 meters. At altitudes between 6,000ft / 1828 meters and 13,100ft / 4,000 meters, the efficiency will decrease to less than 90%.
Safety System:
① Current overload or line surge auto-shutdown. ② High temperature compressor auto-shutdown. ③ High pressure alarm and auto-shutdown. ④ Low pressure alarm and auto-shutdown. ⑤ Low oxygen concentration alarm.
Minimum Operating Time: 3
30 minutes
Electric Classification:
Class Ⅱ equipment, Type BF applied part (Nasal oxygen cannula)
Mode of Operation:
Continuous duty
